HES 9400 Series Electric Strike

The HES 9400 Series Electric Strike Is a Slim-Line Outdoor Rated Surface Mounted Strike Designed to Accommodate Rim Exit Devices with a 1/2" Pullman Latch. All Components Are Completely Encased Within the 5/8" Thick Stainless Steel Housing of the Strike, and Not Cutting of the Frame is Ever Required for Installation. Simply Place the Electric Strike on the Surface of the Frame, Align it with the Exit Latchbolt and Install. The 9400 Strike is Grade 1, Field Selectable (Fail Safe or Fail Secure), Dual Voltage (12VDC, 24VDC) and Comes With a 1/8" Spacer Plate for Varying Door Gaps.

9400 Series Electric Strike Features

• Installs in Metal or Wood Frames
• Completely Surface Mounted
• Dual Voltage: 12VDC or 24VDC
• Field Selectable: Fail Secure or Fail Safe

• Separate Base and Decorative Cover for Easy Adjustments

• Stainless Steel Construction
• Tamper-Resistant
• Static Strength 1,500 Lbs.

• Dynamic Strength 70 ft-Lbs.
• Endurance 500,000 Cycles
• Horizontal Adjustment

• Non-Handed
• Includes 1/8" & 1/16" Spacer Plate
• Internally Mounted Solenoid

• Accommodates up to 3/4" Pullman Latch
• Five-Year Limited Warranty


Choose Bolt Monitor

• 9400: Standard (No Monitor)
• 9400-LBM: Latchbolt Monitor (LBM)
• 9400-LBSM: Latchbolt Strike Monitor (LBSM)

Choose Finish

• 630 - Satin Stainless Steel
• 605 - Bright Brass
• 606 - Satin Brass
• 612 - Satin Bronze
• 613 - Bronze Toned
• 613E - Dark Oxidized Satin Bronze Powder
• 629 - Bright Stainless Steel
