Use Mechanical Overrides: There Is a Mechanical Override Built In to the Kiosk So Users Can Retrieve Their Items From The Locker In Case Kiosk Ever Loses Power.
To Open Three Center Lockers:Open the HMI Locker Using the Included Key. Located the Red Knob On the Bottom Left of the Locker. Pull Up On Knob Fully and the Center Lockers Will Open.
To Open Four Large Bottom Lockers:Open the HMI Locker Using the Included Key. Inside, There Is a Pouch With a Different Key. Use This Key to Operate the Lock at the Very Bottom of the Kiosk.
To Open Small Lockers on Left or Right:Use the Access Key to Open the Top Electronics Box. Locate the Handles With Red Knobs On the Left and Right Side. Pull These Levers to Open the Left or Right Two Rows of Lockers.
How to Clear a Single User's Data:Navigate to Menu > Locker Manage. Then in the Specific Column "Operate", Tap Clear to Open That Specific Locker.
How to Clear All User Data:Navigate to Menu > Locker Manage. Then Tap "Clear All" in the Top Right Corner.
The Breeze Facility Storage Setup Steps
$3,983.00$4,800.00
You save: 17% ($817.00)
SKU-Z-BREEZE
BreezeSetup Instructions
Plug In Kiosk - For Travel, the Power Cable Is Placed Inside the Electrical Box. Use the Provided Key To Unlock the Locker, Feed the Cord Through the Hole in the Back of the Kiosk and Plug the Box In.
Admin Login - After the Kiosk Is Powered Up, Tap the Screen Once to Start. Once on the Next Screen, Tap the Upper Right of the Screen (Where the Clock Is) Several Times Until the Login Screen Appears and Enter the Provided Admin Username and Password.
Set the Kiosk to Public - After Logging In, You'll be Brought to the Menu. From Here, Navigate to Menu > System Settings > Mode Settings. In the Mode Settings Window, Ensure the Kiosk Is Set to "Public".
Set Kiosk to One Cabinet Per User - Navigate to Menu > System Settings > Operation Settings > Locker Quantity. On This Screen, Select "One Locker Per User".
Set Kiosk For Different Cabinet Sizes - Navigate to Menu > System Settings > Operation Settings > Locker Size. On This Screen, Select "Large, Medium Small".
Let Users Choose a Locker- Navigate to Menu > System Settings > Operation Settings > Save Allocation. On This Screen, Select "User Own Choose".
Set Numbers of Lockers- Ensure that the Correct Number of Lockers Is Programmed Into the HMI by Navigating to Menu > Factory Settings. On This Screen, Add Up the Number of Lockers Listed in the Column "Quantity" and Make Sure it Equals the Total Number of Lockers on the Kiosk.
Set Locker Size- Navigate Back to Menu. Then Navigate to Menu > Locker Manage. On This Screen, There Are Several Columns. In the Size Column, Tap Each Locker and Assign it the Respective Size Based on Number.
